Karaoke Microphone User Manual

Karaoke Microphone User Manual

Buttons and functions description

• Buttons operation

1. “”     Hold: ON/OFF    Press: Mode switching

2. “”

Press: the previous song under MP3 mode.

Under selfie mode, press it to enable selfie function (only for iOS system mobile phone)

3. “”

Press: the previous song under MP3 mode.

Under selfie mode, press it to enable selfie function (only for Android system mobile phones)

4. “”

Press: Play/Pause.

Under FM state, hold it for automatic search.

5. “M”

Press: Mike ON/OFF

Hold: Replay function under TF card play mode

6. “+”    Increase volume

7. “-”   Decrease volume

• Wireless Karaoke

1. Supply power: Hold “” to start the product.

2. Wireless connection: enable the wireless of mobile phone, click to connect successful connection if the prompt tone is produced.

3. Adjust sound: adjust the sound volume of the mike and the reverberation to a suitable level.

4. Start Karaoke.

• Recording with mobile phone

1. Connect the recording wire: insert the MICRO plug of the recording wire into the MICRO interface of Karaoke Treasure, and the 3.5mm interface into the earphone jack of the mobile phone.

2. Open the Karaoke software on the mobile phone, such as USING, Kugou Music, or other recording apps, select your favorable song, record the song according to the above-mentioned singing method.

3. Test and save the song: operate according to the instructions of Karaoke software.

• Selfie function

1. Press the “” button to switch from wireless mode to selfie mode;

2. Enable wireless in the mobile phone, search “shutter”, click connection;

3. Open the photograph interface of the mobile phone, press the“”   or“”     button to take photos.

Note: 4.2.2 or higher version for Android system, 6.0 or higher version for iOS system, it temporarily doesn’t support other versions. It doesn’t support the mobile phone which has an independent and solid photograph button.

Technical Parameters

• One set includes:  microphone, USB charging cable, audio cable, instruction manual

• Material: aluminum alloy

• Size: 25 * 9.9 * 9.5cm

• Connection mode: Bluetooth 4.2

• Connection distance: 10m

• TF card supported up to 32 GB

• Output Power: 5W

• Max Sound Pressure Level: >115db 1kHz TDH<1%

• Reverberation Mode: sound effect reverberation

• Power Supply: Built-in 18650 Li-battery

• Battery Capacity: 2000mAh

• Charging time: 2h

• Usage time: 3h

• Frequency Range: 100HZ-10kHz

• Charging Power: DC5V
